SPDP
- IP23 (Screen Protected Drip Proof), IC01
- Motors are basically rated for S1 (continuous duty) but can be adapted to other duties such as S6, S7, S8 etc
- Class 'F' insulation (temperature rise limited to class 'B')
- 3 phase, 415 volt ± 10%, 50 cycle ± 5% as standard
- Continuously rated
- Tropicalisation treatment is provided as a standard practice
- Horizontal footmounted - B3 mounting as standard
- Vertical flange mounting - V1 construction available for frame sizes RW105, RW120, RW136, RW152 and RW168
